Linear Led Driver 100W Dimmable 24V Led Driver

Details

Fahold's LED drivers solve the compatible problem between fluorescent lamps and LED lamps very successfully. They are widely used with various kinds of capacity dimming system to control the LED ceiling light, LED downlight, LED panel lights, LED wallwashers, LED strip lights and so on. Our 0-10V/1-10V dimmers support both linear and logarithmic dimming curve, dimming the lights very smoothly and are compatible with various famous lighting control systems, such as Lutron, Dynalite, Schneider, Clipsal, Osram, Philips, ABB and so on.

HR100W-02-24V, designed specifically for Constant voltage led strips, led linear lights applications, to operate general Linear Lighting Fixtures. Constant voltage 24V Flicker free 0-10V/PWM/RX dimming LED Driver Slim 100W 4000mA, with wattage range of 100W ,UL,FCC,CE compliant, wide voltage output of non waterproof design. The units are suitable for led strips & Linear lighting. Other standard features of the range including 100-277V , protections against short circuit, over load and thermal to 110 °C, across the whole surface of the unit.

Standard features of this LED lighting driver include short circuit, over load, over voltage & over temperature protections and the unit is designed to meet TUV, EN61347-1, EN61347-2-13 and emmisions to EN 55105, EN61547.

Product Specs:

Output voltage:24V

Max. Output wattage: 100W

Max. Output Current: 4000mA

Dimensions:372x39x28mm

Efficiency:90%

Electronic Led Dimmer

Encironment/IP Rating: indoor/IP20

Flicker free

Max. Input voltage:277V

Certificate:UL,FCC,CE

H100W-02-24, 24V 100W led driver constant voltage dimmable driver, Flicker free 0/1-10V/PWM/RX dimming, linear lighting solutions, Desigen for high lumen Linear lights AND High quality led strips. Energy saving driver. Its housing was made out of long shape iron, independent design for the output connection structure, suitable for Europe market & North American market.
